Hobbywing Ezrun MAX10 G2 ESC 80 Amp, 2-3s LiPo, BEC 5A
Please inform me as soon as the product is available again.
- Part No: HW30102604
- Retail: €57.90
- EAN: 6938994405553
- Notice: 30102604
80 A Brushless Sensored ESC for 1/10 Short Course trucks with 2–3S LiPo input The... more
Product information "Hobbywing Ezrun MAX10 G2 ESC 80 Amp, 2-3s LiPo, BEC 5A"
80 A Brushless Sensored ESC for 1/10 Short Course trucks with 2–3S LiPo input
The second-generation Ezrun MAX10 G2 is an 80 A ESC for 1/10 Short Course trucks. Its improved sensor mode uses a waterproof cable and provides throttle response, especially when paired with an Ezrun 3652/3665 G3 motor. Compared with the previous generation, it has stronger and more stable power output and linear response at low speeds.
The capacitor capacity has been increased by 74%, and the capacitors are protected against overheating. This improves power transmission from the battery to the ESC and makes overcharging less likely than before.
Highlights
- Sensor cable design protects against water and dust; suitable for all weather conditions
- Built-in Super BEC
- Frameless smart fan
- Real-time data and data recording
- Turbo timing setting
- Protection against low voltage, overheating and loss of signal
Specifications
| Type | 1/10 Brushless Sensored |
| Current (Cont./Peak) | 80 A / 520 A |
| Input Voltage | 2–3S LiPo |
| BEC | 6 V/7.4 V, 5 A |
| Motor Types | Brushless Motors (with/without sensor) |
| Motor Limit | 2S LiPo: KV ≤ 6000 / 3S LiPo: KV ≤ 4200 3652 Motor |
| Fan | Yes, powered by BEC |
| Fan Size | 25 × 25 × 10 mm |
| Programming | LED Program Box / LCD Program Box (G2) / OTA Program Module / Separate Programming Port |
| Waterproof | Yes |
| Input | XT60 |
| Output | 4.00 mm Gold (female) |
| Dimensions | 53 × 39.5 × 37.2 mm |
| Weight | 120 g |
| Application | 1/10 On-Road/Off-Road Short Course Truck (light-duty) |
In the box
- 1× MAX10 G2 80A ESC
Notes
- Optional accessories: LED Program Card (HW30501003), LCD G2 Program Box (HW30502001), OTA Program Module (HW30850400).
