Power HD 1810S Digital Servo 3.9KG/0.13sec@6.0V
- Part No: PHD017
- Retail: €29.90
- EAN: 6939182018203
- Notice: 1810S
Digital servo for the CAPO CD1582X with a 365 mm connector wire The 1810S is an upgraded... more
Product information "Power HD 1810S Digital Servo 3.9KG/0.13sec@6.0V"
Digital servo for the CAPO CD1582X with a 365 mm connector wire
The 1810S is an upgraded servo based on the 1810MG, customised for the CAPO CD1582X car. A non-conducting potentiometer addresses signal interference between the older 1810MG output gear and the car's metal parts. The signal wire has been extended to 365 mm.
Specifications
| Torque (4.8 V) | 3.10 kg-cm (43.05 oz/in) |
| Torque (6.0 V) | 3.90 kg-cm (54.16 oz/in) |
| Speed | 0.16 s (4.8 V) · 0.13 s (6.0 V) |
| Operating Voltage | 4.8–6.0 V DC |
| Weight | 15.8 g (0.56 oz) |
| Bearing Type | Ball Bearing × 1 |
| Motor Type | DC Motor |
| Gear Type | Copper |
| Connector Wire Length | JR 365 mm |
| Operating Temperature | -20–60 °C |
| Operating Frequency | 1520 µs / 250 Hz |
| Dimensions | 22.8 × 12.0 × 29.4 mm (0.90 × 0.47 × 1.16 in) |
| CAPO CD1582X Servo Recommendation | |
|---|---|
| Steering Servo | T50-BHV |
| Diff Servo | 1810S * 2 |
| Shift Servo | 1810S |
| Control Wheel Linked Servo | 1810S |
