XRotor 2207 D28x19 D5 1780kV 6s LiPo
XRotor 2207.5 1780kV motor for 6S LiPo with self-cooling propeller mount
- Item number
- HW30418009
- EAN
- 6938994417440
€16.90incl. VAT, plus shipping
RRP €16.90
Description
The XRotor 2207.5 1780kV motor is designed for smooth handling and efficient freestyle flying.
Notes
- Recommended with XRotor FPV G2 65 A ESC and HQ-51477 and GF-F4 S props on 6S LiPo.
Highlights
- 1780kV: higher torque for control in smooth, precise freestyle flying
- Electromagnetic optimisation provides more torque at low RPM for responsive control
- Self-cooling propeller mount dissipates heat from the coils, improving efficiency and lifespan
- Anti-slip tooth design on the propeller mount prevents propeller slippage and increases flight safety
- 0.2 mm stator laminations, arc-shaped high-temperature magnets and 220 °C R-class winding wire
Specifications
| Model | XRotor 2207.5 (1780kV) |
|---|---|
| kV Rating | 1780kV |
| LiPo Cells | 6S |
| No-Load Current (at 24 V) | 2.7 A |
| Max. Continuous Current (3 s) | 41 A |
| Max. Continuous Power (3 s) | 988 W |
| Max. Thrust (HQ-51477) | 1827 g |
|---|---|
| Weight (with cable) | 38 g |
| Dimensions | Ø 28 × 19.9 mm |
| Stator (Slot/Pole) | 12N14P |
| Internal Resistance | 76 mΩ |
| Shaft Ø | 5 mm + M5 |
