Xerun XR10 Stock Spec Brushless ESC 80A, 1s LiPo, BEC 3A
Brushless ESC for 1S LiPo with 80 A continuous current and 3 A BEC
- Item number
- HW30112751
- EAN
- 6938994408431
€116.90incl. VAT, plus shipping
RRP €116.90
Description
The XR10 Stock Spec (1S) is a Brushless ESC for 1/12 and 1/10 competitions. It weighs 23.5 g without cable and has a switch-mode BEC selectable between 6 V and 7.4 V at 3 A for use with high-voltage servos. Its 30 programmable parameters include a zero timing function.
Notes
- Optional accessory: LCD Programming Box (HW30502001).
Highlights
- 5 pre-programmed profiles, including zero timing, practice and stock modes
- Small and light for 1/12 use
- 30 programmable parameters
- Adjustable braking modes, PWM and braking frequency
- Turbo Timing and Boost Timing functions
- Programmable with the LCD Programming Box
- Real-time data logging for temperature, speed and more
- Protection against undervoltage, overheating and signal loss
Specifications
| Type | Brushless |
|---|---|
| Current (Cont./Peak) | 80 A / 380 A |
| Input Voltage | 1S LiPo / 3–4S NiMH |
| BEC | 6 V/7.4 V @ 3 A (Switch-Mode) |
| Motor Type | Brushless Motors with/without sensor |
| Motor Limit | T ≥ 10.5T (3650 Motor) |
| Fan | Yes |
|---|---|
| Programming | LCD Programming Box |
| Dimensions | 31.6 × 25.8 × 16.2 mm |
| Weight | 23.5 g (without cable) |
| Application | 1/12 Stock |
