Product information "Hobbywing Xerun AXE Plus R3 ESC for Crawler"
The XeRun AXE Plus R3 Brushless FOC ESC provides a powerful solution for crawler RC cars of various sizes. With support for up to 6S LiPo batteries and a maximum continuous current of 135A, it is versatile and, thanks to the integrated FOC technology, delivers linear performance, ample torque, and nearly silent operation - ideal for challenging terrain.
The intelligent control also allows for automatic adjustments of torque for effortless climbing and hill descents, while the smart fan control starts only when necessary to save energy and optimize operating temperature during the ride. With the built-in Bluetooth module, the ESC can be directly connected to the mobile app for parameter adjustments, data monitoring, and firmware updates. It also supports data logging for detailed performance analysis. New to this generation is the support for I-BUS2 telemetry on Flysky NB4 transmitters, for which a dedicated data acquisition function has been implemented. This allows real-time display of data such as battery voltage, motor speed, operating current, controller and motor temperature, as well as many other information on the transmitter.
To ensure smooth operation, the AXE Plus R3 ESC is IP67-rated, protecting it from water and dust and making it therefore suitable for extended rides in various weather conditions. With its versatility and wide range of adjustable parameters, the XeRun AXE Plus R3 ESC provides optimal performance and control for crawler cars under diverse requirements.
Features
Stronger performance thanks to FOC (Field-Oriented-Control) technology.
Drag brake adjustable up to 200% for unparalleled holding power on slopes.
Super BEC with max. 6A and three voltage levels for using different servos.
Waterproof and dustproof to IP67 standard.
Smart torque delivery and speed control for easy control and constant speed under all loads.
Built-in Bluetooth module.
Multiple controller protection functions including reverse polarity protection.
Only compatible with Xerun AX "R2" and "R3" motor series.
Technical Specifications
Type:
Brushless Sensored FOC
Current (cont./peak):
135A / 600A
Cells:
2S-6S LiPo
Motor Limits:
Only supports Xerun-AXE "R2" and "R3" motor series
AXE R2: 540 / 540L / 550
AXE R3: 4274
BEC:
6V / 7.4V / 8.4V @ 6A (Switch Mode)
Waterproof:
Yes
Cables:
1x 12AWG (black, 265mm) 1x 12AWG (red, 265mm)
Fan:
25 x 25 x 10mm, powered by BEC
Connectors:
XT60
Programming:
Per Bluetooth and "HW LINK"-App
Firmware Upgrade:
Yes
Dimensions:
49.5 x 37.9 x 32.8mm
Weight:
126.5g
Application:
1/10, 1/8, 1/6 Rock Crawler
Delivery
1x Xerun AXE Plus R3 ESC
1x Manual
