Xerun 4274SD Brushless Motor G3 2250kV Truck Monster
1/8 Brushless Sensored motor, 2250kV, for trucks and monster trucks
- Item number
- HW30405001
- EAN
- 6938994419741
RRP €131.90
Description
The Xerun 4274SD G3 motor is designed for 1/8 truck models. Its improved design increases the efficiency in combating generated heat by 6% compared with G2 predecessor motors, which significantly reduces heat generation.
A built-in chip allows Hobbywing Xerun XR8 ESCs to recognise the motor and form a fully sensor-controlled driving system. The Hall sensor system provides a clean and stable run in sensor mode.
Turbo Timing can be activated when the motor is used with an ESC from the XERUN XR8 series and releases the last power reserves of the motor. Turbo Timing is also used in 1/10 on-road models.
Notes
- Sensor mode is not guaranteed when the motor is connected to other ESCs.
Highlights
- Low heat development
- Low detent torque
- High quality materials and excellent workmanship
- Easy installation
- Dustproof to IP5X (1900kV, 2200kV and 2250kV)
Specifications
| Scale | 1/8 |
|---|---|
| Type | Brushless Sensored |
| kV Rating | 2250kV |
| No-Load Current | 5 A |
| LiPo Cells | 2–6S |
| Poles | 4 |
| Length | 74 mm |
|---|---|
| Diameter | 42 mm |
| Shaft Diameter | 5 mm |
| Weight | 354 g |
| Timing | 20–40 degrees (adjustable) |
| Application | 1/8 Truck, Monster Truck |
In the box
- 1 × Motor
- 1 × Sensor cable
- 1 × Manual
Documents
Safety & manufacturer
Manufacturer
Hobbywing
Item number: HW30405001
EAN: 6938994419741
Responsible person in the EU
Safety information
- Contains small parts.
- Keep away from children.
- Not suitable for children under 14 years of age.
