Hobbywing QuicRun WP10BL60 G2 Brushless ESC 60A 2-3s for 1:10
- Part No: HW30107300
- Retail: €47.90
- EAN: 6938994413220
- Notice: Sensorless,30107300
The 2nd generation of the Quicrun WP10BL60 controller is a classic, solid brushless solution for 1/10 on-road vehicles, buggies, and short course trucks. Compared to its predecessor, small but quite modern changes have been made. First and foremost, the G2 controller is now more resistant to high heat thanks to the intelligent freewheeling technology and features an overheating protection for the capacitors. This protection effectively prevents the integrated capacitors from bursting due to high temperatures, which can lead to total failure in conventional controllers without protection. The air vents in the controller's design also provide efficient cooling, while each phase has a copper heat protection strip to further support the cooling effect. This ensures that drivers can stay cool in even the most critical situations.
The QuicRun series from Hobbywing offers a cost-effective alternative for all drivers who want to achieve more with their setups - whether with brushless motors or not. It is primarily aimed at beginner and intermediate pilots and impresses with the outstanding quality known from Hobbywing products as well as the uncomplicated commissioning.
Features:
- Equipped with modern overheat protection
- Top performance at a low price
- More compact design than the predecessor, fitting a variety of chassis
- Ideal for many applications and competitions
- Programmable via LCD Programmer Box Pro, LED Programmer Box, and SET button
- Waterproof and dustproof according to IP67 standard*
- Various protection functions:
- Overheat protection
- Low voltage cutoff
*The aforementioned IP67 protection level means that the ESC is splashproof, water-repellent, and dustproof under normal use. The protection is not permanently effective, and its performance may decrease due to daily usage and/or aging. Do not submerge the controller in water for extended periods, as this may cause damage.
Technical Specifications:
| Type: | Brushless, Sensorless |
| Current (cont./peak): | 60A / 360A |
| Input Voltage: | 2-3S LiPo |
| BEC: | 6V / 3A (Switch Mode) |
| Motor Types: | Brushless Motors (with/without sensor) |
| Motor Limit: | 2S: <= 6000kV 3S: <= 3500kV, 3652/3660 motor |
| Waterproof: | Yes |
| Data Recording: | No |
| Cables: | 2x 14AWG (black & red, 150mm) 3x 14AWG (black, 60mm) |
| Output: | 4.00mm Gold (female) |
| Fan: | Yes, powered by BEC |
| Fam Size: | 30 x 30 x 10mm |
| Programming: | SET button LED Programm Box LCD Programm Box Pro |
| Dimensions: | 46 x 36.5 x 34.3mm |
| Weight: | 86.6g |
| Application: | 1/10 On-Road, Buggy, Short Course Truck |
Optional Accessories:
- HW30502002 LCD Programm Box Pro
- HW30501003 LED Programm Box
Delivery:
- Quicrun 10BL60 G2 ESC
- Manual
