Hobbywing Quicrun Fusion Pro Elite 2300kV 2-4s
- Part No: HW30120500
- Retail: €131.90
- EAN: 6938994412384
- Notice: 30120500
Compact 2-in-1 motor and ESC for 1/10 Crawlers, with FOC drive and 2–4S LiPo support The... more
Product information "Hobbywing Quicrun Fusion Pro Elite 2300kV 2-4s"
Compact 2-in-1 motor and ESC for 1/10 Crawlers, with FOC drive and 2–4S LiPo support
The Hobbywing QuicRun Fusion Pro Elite combines a motor and ESC in a 2-in-1 design. It is the latest generation of the Fusion series.
FOC drive technology (Field-Oriented Control) provides low-speed torque and smooth, quiet operation for precise crawling and controlled driving in demanding terrain. Intelligent torque management and closed-loop control regulate speed and power.
The ESC supports 2–4S LiPo and has a maximum continuous output current of 50 A.
Highlights
- 48.5 mm total length: 9.5 mm shorter than the QuicRun Fusion Pro and 1.3 mm shorter than the AXE 540
- Drag Brake and other parameters adjustable in real time via AUX channel
- 5 operating modes
- Fully waterproof and dustproof according to IP67
Specifications
| Type | Brushless FOC, Sensored |
| Continuous / Peak Current | 50 A / 150 A |
| Cells | 2–4S LiPo |
| BEC | 6 V / 7.4 V / 8.4 V @ 5 A |
| Length | 48.5 mm |
| Outer Diameter | 37 mm |
| Shaft Diameter | 3.175 mm |
| Waterproof | Yes, IP67 |
| Weight | 178.5 g |
| Application | 1/10 Crawler |
In the box
- 1× QuicRun Fusion Pro Elite
- 1× User manual
