Brand:
Ezrun MAX5 HV Plus G2 ESC 300 Amp, 6-12s LiPo, BEC 6A
High-voltage Brushless Sensored ESC for 6–12S LiPo with integrated Bluetooth
- Item number
- HW30104300
- EAN
- 6938994405607
€268.90incl. VAT, plus shipping
RRP €268.90
Description
The EzRun MAX5 HV Plus G2 is a high-voltage brushless ESC for 6–12S LiPo. With a 2-pole motor, speeds of up to 300,000 RPM are possible.
The data logging module records and stores up to 10 minutes of operational data. Turbo timing with EzRun 5690/56118 G2 motors increases maximum speed by 18%.
The 4080 µF capacitor has integrated overheat protection. AS150 anti-spark connectors prevent sparks when connecting HV LiPos.
Highlights
- Intelligent freewheeling function to improve efficiency and lower operating temperature
- Integrated Bluetooth for the app
- Data logging
- IP67 protection class
- Turbo timing (24 degrees) with EzRun 5690/56118 G2 motors
- 4080 µF capacitor with integrated overheat protection
- AS150 anti-spark connectors
Specifications
| Type | Brushless Sensored |
|---|---|
| Current (Cont./Peak) | 330 A / 2000 A |
| Input Voltage | 6–12S LiPo |
| BEC | 6 V/7.4 V/8.4 V @ 8 A |
| Motor Types | Brushless motors (recommended: EzRun 5690/56118SL G2) |
| Fan | Yes |
| Programming | LCD G2, LCD Pro, OTA, Bluetooth |
|---|---|
| Output | 8.00 mm Bullet Connector (female) |
| Dimensions | 94.5 × 59.4 × 51.6 mm |
| Weight | 450 g |
| Application | 1/5, 1/7, 1/8 |
Documents
Safety & manufacturer
Manufacturer
Hobbywing
Item number: HW30104300
EAN: 6938994405607
Responsible person in the EU
Robitronic Electronic GmbH
Pfarrgasse 50, 1230 Wien, Austria (AT)
Safety information
- Contains small parts.
- Keep away from children.
- Not suitable for children under 14 years of age.
