Product information "Flysky FTR16S AFHDS3 Receiver 16CH"
The FTr16S receiver is the ideal support when using a Flysky remote control. The receiver makes use of a technology used by several Flysky transmitters - the automatic frequency hopping digital system (short: AFHDS3). This receiver is specially designed for the installation and output of PPM/i-BUS and S.BUS signals.
Technical Specifications
PWM-Channels:
16
RF:
2.4GHz
Protocol:
AFHDS 3
Antennas:
Dual (2x92.5mm)
Input Voltage:
3.5-8.4V
Output:
PPM/i-BUS/S.BUS
RSSI:
Yes
Temperature:
-15°C to +60°C
Max. Humidity:
20%-95%
Update:
Yes, online
Dimensions:
20x12x3.1mm
Weight:
<2g
Suitable for:
Racing drones
Compatible Transmitter:
all AFHDS3-Transmitter
