Description
The DSSERVO CLS3325 is a compact coreless servo with up to 39 kg·cm torque.
Highlights
- Coreless motor for high speed
- Torque up to 39 kg·cm at 8.4 V
- Full metal housing made of stainless steel and aluminium
- Response speed up to 0.065 s/60°
- Control with 2 µs deadband
- PWM compatible; frequency: 1520 µs / 333 Hz
Specifications
| Voltage | 5.0 V · 7.4 V · 8.4 V |
|---|---|
| Torque | 26 kg·cm (5.0 V) · 35 kg·cm (7.4 V) · 39 kg·cm (8.4 V) |
| Speed | 0.11 s/60° (5.0 V) · 0.075 s/60° (7.4 V) · 0.065 s/60° (8.4 V) |
| Motor | Coreless |
| Gears | Stainless steel and aluminium |
| Dimensions | 40 × 20 × 40.5 mm |
|---|---|
| Weight | 60 g |
| Frequency | 1520 µs / 333 Hz |
| Deadband | 2 µs |
Safety & manufacturer
Manufacturer
DS Servo
Item number: DS020
EAN: 4046032111648
Responsible person in the EU
Robitronic Electronic GmbH
Pfarrgasse 50, 1230 Wien, Austria (AT)
Safety information
- Contains small parts.
- Keep away from children.
- Not suitable for children under 14 years of age.
