Description
The DSSERVO BLS3355 is a brushless servo with an all-metal housing and up to 61 kg·cm stall torque.
Highlights
- Brushless motor
- Holding torque up to 61 kg·cm at 0.09 s/60°
- All-metal housing
- Dust- and waterproof to IP67
- Dual ball bearings and 2 µs deadband
- PWM-compatible with 4.8–8.4 V operating range
Specifications
| Voltage | 4.8 V · 6.0 V · 7.4 V · 8.4 V |
|---|---|
| Speed | 0.14 s/60° (4.8 V) · 0.12 s/60° (6.0 V) · 0.10 s/60° (7.4 V) · 0.09 s/60° (8.4 V) |
| Stall Torque | 39 kg·cm (4.8 V) · 47 kg·cm (6.0 V) · 55 kg·cm (7.4 V) · 61 kg·cm (8.4 V) |
| Motor | Brushless |
| Gear Ratio | 366 |
| Type | Digital (PWM) |
| Control Frequency | 50–330 Hz |
|---|---|
| Bearings | Dual |
| Dimensions | 40 × 20 × 38 mm |
| Weight | 85.0 g |
| Angle Range | 180° (500–2500 µs) |
| Waterproof | IP67 |
