Description
The DSSERVO BLS3245 is a brushless servo with IP67 protection.
Highlights
- Brushless motor with strong pulling power
- Torque output up to 49 kgcm
- IP67-certified, waterproof and dustproof
- High-precision control with 2 µs deadband
- Dual ball bearings for smooth operation
- PWM-compatible, operating voltage from 4.8 to 8.4 V
Specifications
| Speed | 0.15 s/60° (4.8 V) · 0.13 s/60° (6.0 V) · 0.11 s/60° (7.4 V) · 0.10 s/60° (8.4 V) |
|---|---|
| Stall Torque | 31 kgcm (4.8 V) · 36 kgcm (6.0 V) · 43 kgcm (7.4 V) · 49 kgcm (8.4 V) |
| Motor | Brushless |
| Gear Ratio | 361 |
| Type | Digital (PWM) |
| Control Frequency | 50–330 Hz |
| Bearings | Dual |
|---|---|
| Dimensions | 40 × 20 × 37.5 mm |
| Weight | 60.0 g |
| Angle Range | 180° (500–2500 µs) |
| Waterproof | IP67 |
Safety & manufacturer
Manufacturer
DS Servo
Item number: DS015
EAN: 4046032111594
Responsible person in the EU
Robitronic Electronic GmbH
Pfarrgasse 50, 1230 Wien, Austria (AT)
Safety information
- Contains small parts.
- Keep away from children.
- Not suitable for children under 14 years of age.
