Digital Servo Waterproof 35.0kg/0.19sec @7.4V
Waterproof DC digital servo with 35.0 kgcm torque at 7.4 V
- Item number
- DWD130
- EAN
- 6959009001300
€41.90incl. VAT, plus shipping
RRP €41.90
Description
The Doyono DC digital servo delivers up to 35.0 kgcm of torque. It has aluminium and copper gears, an aluminium housing and a DC motor.
Highlights
- DC digital servo
- Aluminium and copper gears
- Lightweight aluminium housing
- Waterproof
- Operating voltage: 6.0–7.4 V
- 2 µs dead band, 1520 µs neutral point
- Connection wire length: 360 mm
Specifications
| Speed | 0.21 s (6.0 V) · 0.19 s (7.4 V) |
|---|---|
| Torque | 29.0 kgcm (6.0 V) · 35.0 kgcm (7.4 V) |
| Motor | DC |
| Gears | Aluminium / Copper |
| Bearings | yes, dual |
| Max. Travel | approx. 130° (at 800: 2200 µs) |
| Quiescent Current | 40 mA @6.0 V |
| Rated Current | 0.7 A @6.0 V |
|---|---|
| Stall Current | 3.2 A @6.0 V |
| Dimensions | 40.7 × 20.5 × 38.9 mm |
| Weight | 84.0 g |
| Spline | 25T |
| Application | RC Crawler, 1/10 and 1/8 Off-Road, Electric Boats |
Safety & manufacturer
Manufacturer
Doyono
Item number: DWD130
EAN: 6959009001300
Responsible person in the EU
Robitronic Electronic GmbH
Pfarrgasse 50, 1230 Wien, Austria (AT)
Safety information
- Contains small parts.
- Keep away from children.
- Not suitable for children under 14 years of age.
